Product Details
| Parameters Measured | ECG, SpO₂, NIBP, RESP, TEMP |
| Type of display | Color TFT LCD |
| Display Size | 7 inch |
| Suitable for | Adult and Neonatal |
| Brand | Nidek |
| Model | Aurus 50 |
NIBP
| Measurement Mode | Intelligent Oscillation Mode |
| Cuff Inflating Time | <30 sec |
| Initial Cuff Inflating Pressure | Adult Mode – 180 mm Hg Neonate Mode – 120 mm Hg |
| Maximum Allowed Inflating Pressure | 300 mm Hg |
| Measuring Deflating Time | Average <90 sec |
| Accuracy of Blood Pressure | Maximum Average Error 4 mm Hg |
| Resolution of NIBP | 1 mm Hg |
| Protection of Over Pressure | Adult – 300 mm Hg paediatric – 240 mm Hg Neonates – 150 mm Hg |
Peripheral Capillary Oxygen Saturation
| SPO2 Measurement Range | 0 – 100% |
| Accuracy | ≤±2% (70 – 100%) ≤±3% (50 – 69%) |
| Sensor | Two Wave LED |
| Resolution of SpO₂ | 1% |
| Range of Pulse Rate | 40 – 250 beat/min |
| Accuracy of Pulse Rate | ±2 beat/min |
RESP
| Method of RESP | Thoracic Impedance |
| RR Measurement Range | 10 – 100 rpm |
| Accuracy of RESP | 1 bpm |
TEMP
| TEMP Measurement Range | 20 – 45°C |
| Measurement Unit | °C/F Selectable |
ECG
| Lead Configuration | Standard 3 Leads RA, LA, LL |
| Lead Mode | I, II, III, I, II, III, aVR, aVL, aVF, V (7 Leads) |
| 5 Leads Cable | RA, LA, LL, RL and V |
| Gain of ECG | 0.25, 0.5, 1, 2 |
| Heart Rate Range | 30 – 300 bpm |
| Accuracy of ECG | ±10% or 5 bpm (choosing the greater) |
| Resolution of ECG | 1 bpm |
| Sensitivity | >200 uV |
| Input Impedance | >5 MΩ |
Features
- In-built battery back-up & recorder
- Big eyes warning light
- Intelligent pressure oscillation
- 1000 NIBP measurement data storage
- Can be used with Electro Surgical Unit
In The Box
- Device
- SPo2 and PR probe
- ECG Probe and electrodes
- Temp Probe
- Power cable
- Manuals
